Innovating Thermal Management with ZMPC Immersion Cooling Technology
As global demand for high-efficiency thermal management systems continues to rise, immersion cooling technology has become the preferred choice for both energy storage systems (ESS) and data center infrastructure.
ZMPC has developed two next-generation cooling fluids — Immersion Cooling Fluid for Energy Storage Systems and Immersion Dielectric Cooling Fluid for Data Centers — designed to deliver exceptional heat transfer efficiency, dielectric insulation, and long-term operational safety under the most demanding conditions.
The ZMPC Immersion Cooling Fluid for Energy Storage Systems is specifically engineered for direct-contact lithium battery energy storage applications, where safety, reliability, and cooling performance are paramount.
Formulated with coal-based synthetic base oils and proprietary long-life additives, this dielectric coolant ensures excellent insulation, superior thermal conductivity, and outstanding low-temperature flowability. It effectively prevents thermal runaway and enhances the overall efficiency of large-scale ESS operations.
High Flash Point & Low Viscosity: Delivers safe and stable cooling under high-load, high-temperature operation.
Superior Thermal Conductivity: Rapidly absorbs and dissipates heat, maintaining uniform cell temperature across the system.
Excellent Dielectric Strength: Breakdown voltage far exceeds operational system voltage, ensuring electrical reliability.
Chemical Stability & Compatibility: Free from aromatics and mineral oil; fully compatible with metals and polymeric materials in battery packs.
Residue-Free Formula: Prevents varnish or deposit formation during long-term use.
This product is designed for:
Grid-scale energy storage systems (ESS)
Commercial and residential battery storage units
Renewable energy storage integration (solar & wind)
Thermal management for lithium-ion and LFP battery modules
| Property | Unit | Typical Value | Test Method |
|---|---|---|---|
| Density (20°C) | kg/m³ | 796–813 | GB/T 1884 |
| Kinematic Viscosity (40°C) | mm²/s | 6.5–17.9 | GB/T 1995 |
| Pour Point | °C | -69 to -60 | GB/T 3535 |
| Flash Point | °C | 180–240 | GB/T 3536 |
| Breakdown Voltage | kV | 73–84 | IEC 60156 |
The ZMPC Immersion Dielectric Cooling Fluid for Data Centers is a non-conductive thermal management fluid formulated for direct-contact immersion cooling systems in modern IT environments.
It enables data centers to achieve PUE below 1.1, drastically reducing power consumption while maintaining reliable system stability and extended component lifespan.
With high heat transfer efficiency, excellent dielectric strength, and chemical inertness, this cooling fluid ensures both energy efficiency and hardware protection, even in high-density or AI-intensive workloads.
High Thermal Conductivity & Specific Heat: Maximizes cooling efficiency, reducing server overheating and power loss.
Long-Term Dielectric Stability: Maintains high breakdown voltage and resistivity, protecting sensitive electronic components.
Non-Conductive & Safe: 100% non-aromatic, non-corrosive, and free from volatile contaminants.
Extended Service Life: Engineered to perform without film or residue formation, ensuring consistent heat exchange efficiency.
This fluid is ideal for:
Immersion-cooled data centers (IDC)
AI computing clusters and GPU servers
High-density server rooms and HPC facilities
Edge computing and modular micro data centers
| Property | Unit | Typical Value | Test Method |
|---|---|---|---|
| Density (20°C) | kg/m³ | 782–808 | GB/T 1884 |
| Kinematic Viscosity (40°C) | mm²/s | 3.6–10.5 | GB/T 1995 |
| Pour Point | °C | -84 to -60 | GB/T 3535 |
| Flash Point | °C | 143–208 | GB/T 3536 |
| Breakdown Voltage | kV | 68–75 | IEC 60156 |
Why Choose ZMPC Dielectric Cooling Solutions?
With over a decade of expertise in synthetic hydrocarbon fluids and advanced thermal management materials, ZMPC offers custom-engineered cooling solutions for clients in energy storage, data infrastructure, and electronic manufacturing industries.
Our dielectric cooling fluids are RoHS-compliant, environmentally safe, and designed for long-term lifecycle stability, helping customers achieve:
Reduced system energy consumption
Extended equipment lifespan
Enhanced operational safety and reliability
As the demand for energy storage integration and data processing power continues to grow, dielectric immersion cooling fluids are reshaping how industries manage heat and improve efficiency.
Whether in grid-scale energy storage or liquid-cooled data centers, ZMPC Immersion Cooling Fluids deliver the safety, performance, and sustainability needed for the next generation of intelligent thermal management systems.
