Immersion Dielectric Cooling Fluid for Data Centers
ZMPC
ZMPC-03
ZMPC Immersion Dielectric Cooling Fluid is specially formulated for direct-contact data center cooling systems, using ZMPC’s advanced coal-based base oil and proprietary additives. It provides excellent dielectric strength, high heat transfer efficiency, and superior flowability at low temperatures, ensuring stable, safe, and low-energy operation of IDC systems.
High Heat Transfer Efficiency:
Excellent specific heat and thermal conductivity for faster cooling and energy saving.
Long-Term Insulation:
Maintains high dielectric strength and resistivity for reliable insulation performance.
Excellent Compatibility:
Compatible with electronic materials and components, free from mineral oils and aromatics.
Safe & Clean:
Long-life formula that prevents varnish and residue formation on IT hardware surfaces.
Designed for IDC (Internet Data Center) thermal management systems under high-heat conditions.
Ideal for use in liquid immersion data centers, AI computing centers, high-density server rooms, and edge computing facilities.
| Test Item | ZMSH-03 | ZMPC-05 | ZMPC-07 | ZMPC-10 | Test Method |
|---|---|---|---|---|---|
| Appearance | Colorless Transparent Liquid | Colorless Transparent Liquid | Colorless Transparent Liquid | Colorless Transparent Liquid | Visual |
| Density (20°C, kg/m³) | 782.8 | 786.1 | 796.3 | 808.6 | GB/T 1884 |
| Kinematic Viscosity (-40°C, mm²/s) | 128.1 | 290.7 | 490.2 | 1317 | GB/T 265 |
| Kinematic Viscosity (20°C, mm²/s) | 6.051 | 9.017 | 12.38 | 20.94 | GB/T 265 |
| Kinematic Viscosity (40°C, mm²/s) | 3.662 | 5.126 | 6.664 | 10.48 | GB/T 1995 |
| Pour Point (°C) | -84 | -69 | -66 | -60 | GB/T 3535 |
| Flash Point (°C, open cup) | 143 | 152 | 177 | 208 | GB/T 3536 |
| Dielectric Breakdown Voltage (kV, new oil) | 75 | 72 | 73 | 68 | IEC 60156 |
| Specific Heat Capacity (20°C, KJ/kg·K) | 1.97 | 1.99 | 2.02 | 2.12 | ASTM D7896 |
| Thermal Conductivity (20°C, W/m·K) | 0.1312 | 0.1359 | 0.1408 | 0.1443 | ASTM D7896 |
